Linius L.150ACL
Extruded aluminium profile with a perforated bottom with a blind step of 150 mm. To create noise damping qualities, blinds are filled with inorganic mineral wool. Developed to offer an aesthetic solution in a blind wall application where the noise damping factors weigh the heaviest. Acoustic features: Rw (C;Ctr) =Rw (C;Ctr) = 15 (-1;-4) dB
Specifications based on your calculation
Technical Specifications
Physical Free Passage (%) | 34.30 |
---|
| 15 |
---|
slat step (mm) | 150 |
---|
technical.standaardgaastype | - |
---|
technical.ip_klasse | - |
---|
technical.lameldiepte_mm | 222 |
---|
Total louvre depth (mm) | - |
---|
K-factor (entry) | 37.3 |
---|
CE coefficient | 0.164 |
---|
K-factor (discharge) | 41.9 |
---|
CD coefficient | 0.15 |
---|
Water resistance at 0 m/s (%) | - |
---|
Water resistance at 0,5 m/s (%) | - |
---|
Water resistance at 1,0 m/s (%) | - |
---|
Water resistance at 1,5 m/s (%) | - |
---|
Water resistance at 2,0 m/s (%) | - |
---|
Water resistance at 2,5 m/s (%) | - |
---|
Water resistance at 3,0 m/s (%) | - |
---|
Water resistance at 3,5 m/s (%) | - |
---|
technical.standaardgaastype | - |
---|
technical.ip_klasse | - |
---|
technical.lameldiepte_mm | 222 |
---|
Total louvre depth (mm) | - |
---|
K-factor (entry) | 37.3 |
---|
CE coefficient | 0.164 |
---|
K-factor (discharge) | 41.9 |
---|
CD coefficient | 0.15 |
---|
Water resistance at 0 m/s (%) | - |
---|
Water resistance at 0,5 m/s (%) | - |
---|
Water resistance at 1,0 m/s (%) | - |
---|
Water resistance at 1,5 m/s (%) | - |
---|
Water resistance at 2,0 m/s (%) | - |
---|
Water resistance at 2,5 m/s (%) | - |
---|
Water resistance at 3,0 m/s (%) | - |
---|
Water resistance at 3,5 m/s (%) | - |
---|
